Model
KL-N20V
Type
KL-LINK unit
Transmission specification
Communication speed
5 Mbps, 2.5 Mbps, 625 kbps, 156 kbps
Maximum cable length
5 Mbps: 50 m, 2.5 Mbps: 120 m, 625 kbps: 500 m, 156 kbps: 1,200 m
Communication medium
Dedicated cable (shield line with 2-core threads)
Maximum number of connections for expansion station
5 Mbps: 97, 2.5 Mbps: 129, 625 kbps: 129, 156 kbps: 129
Amount of communication data
Max. 2,048 (128 words)
Communication cycle time
2.88 ms/2,048 points (Communication speed 5 Mbps)
Internal current consumption
80 mA or less
Weight
Approx. 100 g
