Product Functions
| Model | Function |
|
JS-24T3-D
|
24 point host, 12DI (NPN) / 12 DO (NPN), including: 2 point maximum 200k high speed input (X0-X1,1 AB phase) / 2 point maximum 50K high speed input, 3 point maximum 200k high speed output (factory default maximum frequency is 100k), 3 drive motors. The C language is not supported, and the program capacity is 16K.
Communication interface: RS232 / RS485 / USB, 16 expansion modules connected to the right side (the maximum digital input / output is 256 / 256), DC24V power supply.
|
|
JS-24T3-A
|
24 point host, 12DI (NPN) / 12 DO (NPN), including: 2 point maximum 200k high speed input (X0-X1,1 AB phase) / 2 point maximum 50K high speed input, 3 point maximum 200k high speed output (factory default
maximum frequency is 100k), 3 drive motors. The C language is not supported, and the program capacity is 16K.
Communication interface: RS232 / RS485 / USB, 16 expansion modules connected to the right side (the maximum digital input / output is 256 / 256), DC24V power supply.
|
|
JSC-24T3-C-D
|
24-point host, 12DI (NPN)/12DO (NPN), including: 2 points of maximum 200K high-speed input (X0-X1, 1 AB phase), 3 points of maximum 200k high-speed output (factory default maximum frequency is 100k), drive motor 3 sets. Support C language, program capacity 30K.
Communication interface: RS232/RS485/CANopen bus (with 16 CAN slaves: such as servo, stepper, valve terminal, etc.), 16 expansion modules can be connected on the right side (the maximum digital input/output of the host is 256/256), DC24V power supply. |
|
JSC-24T3-C-A
|
24-point host, 12DI (NPN)/12DO (NPN), including: 2 points of maximum 200K high-speed input (X0-X1, 1 AB phase), 3 points of maximum 200k high-speed output (factory default maximum frequency is 100k), drive motor 3 sets. Support C language, program capacity 30K.
Communication interface: RS232/RS485/CANopen bus (with 16 CAN slaves: such as servo, stepper, valve terminal, etc.), 16 expansion modules can be connected on the right side (the maximum digital input/output of the host is 256/256), AC100V-240V power supply |
|
JSC-24T6-D
|
24-point host, 12DI (NPN)/12DO (NPN), including: 2 points maximum 200k high-speed input (X0-X1, 1 AB phase) / 2 points maximum 50K high-speed input, 6 points maximum 200k high-speed output (factory default maximum frequency is 100k), drive motor 6 sets. Support C language, program capacity 30K. Communication interface: RS232/RS485/USB, 16 expansion modules can be connected on the right side (the maximum digital input/output of the host is 256/256), DC24V power supply.
|
|
JSC-24T6-A
|
24-point host, 12DI (NPN)/12DO (NPN), including: 2 points maximum 200k high-speed input (X0-X1, 1 AB phase) / 2 points maximum 50K high-speed input, 6 points maximum 200k high-speed output (factory default maximum frequency is 100k), drive motor 6 sets. Support C language, program capacity 30K. Communication interface: RS232/RS485/USB, 16 expansion modules can be connected on the right side (the maximum digital input/output of the host is 256/256), AC100V-240V power supply.
|
|
JSC-24T6-DS
|
24-point host, 12DI (NPN/PNP)/12DO (NPN), including: 2 points maximum 200k high-speed input (X0-X1, 1 AB phase) / 2 points maximum 50K high-speed input, 6 points maximum 200k high-speed output (factory default maximum frequency is 100k), drive motor 6 sets. Support C language, program capacity 30K.
Communication interface: RS232/RS485/USB, 16 expansion modules can be connected on the right side (the maximum digital input/output of the host is 256/256), DC24V power supply. |
|
JSC-24T6-AS
|
24-point host, 12DI (NPN/PNP)/12DO (NPN), including: 2 points maximum 200k high-speed input (X0-X1, 1 AB phase) / 2 points maximum 50K high-speed input, 6 points maximum 200k high-speed output (factory default maximum frequency is 100k), drive motor 6 sets. Support C language, program capacity 30K.
Communication interface: RS232/RS485/USB, 16 expansion modules can be connected on the right side (the maximum digital input/output of the host is 256/256), AC100V-240V power supply. |
Naming Rules
Product Features
-
The M point is M0-M19999, D is D0-D29999, and the power-down hold range is the same as JS.
-
All series of the same firmware, the whole series supports C language.
-
50% faster processing speed than JS series.
-
USB flash drive compatibility is higher and can recognize USB 2.0, USB3.0 USB flash drive.
-
The firmware supports updating in a power-on state
Product wiring
Product size
