Product characteristics
Type of light
red light
Housing
threaded type
Dimensions [mm] M18 x 1 / L = 60
Application
Function principle
Through-beam sensor
Electrical data
Operating voltage [V] 10…36 DC
Current consumption [mA] 10
Protection class
II
Reverse polarity protection
yes
Type of light
red light
Wave length [nm] 624
Outputs
Electrical design
PNP
Output function
light-on mode
Max. voltage drop switching output DC [V] 2.5
Permanent current rating of switching output DC [mA] 150; (200 (…60 °C))
Switching frequency DC [Hz] 1000
Short-circuit protection
yes
Type of short-circuit protection
pulsed
Overload protection
yes
Detection zone
Transmitter / receiver
receiver
Range [m]
