Product characteristics
Type of light
red light
Communication interface
IO-Link
Housing
rectangular
Application
Function principle
Through-beam sensor
Electrical data
Operating voltage [V] 10…30 DC
Current consumption [mA] 16
Protection class
III
Reverse polarity protection
yes
Type of light
red light
Wave length [nm] 662
Outputs
Electrical design
NPN
Output function
dark-on mode
Max. voltage drop switching output DC [V] 2.5
Permanent current rating of switching output DC [mA] 200
Switching frequency DC [Hz] 1000
Short-circuit protection
yes
Type of short-circuit protection
pulsed
Overload protection
yes
Detection zone
Transmitter / receiver
receiver
Range [m]
